Automotive System Integration Testing (SIT) FRAMEWORK
A few years ago, collision and lane change avoidance technology were primitive. Nowadays, the technology has been updated with advanced driver assistance systems (ADAS). These new systems introduced a new design and test challenges. Modern ADAS architecture combines complex sensing, processing, and algorithmic technologies into what will ultimately become the guts of autonomous vehicles. As ADAS evolve from simple collision-avoidance systems to fully autonomous vehicles, they demand sensing and computing technologies that are complex. This need creates a demand for quality assurance and testing techniques. In particular, hardware-in-the-loop (HIL) test methods have been adapted to ADAS setups, with the purpose of using real sensors to emulate ECMs and generate actuator control signals.
HIL methods verify and validate the software in the physical target ECUs. HIL test benches can provide the ECU with realistic real-time stimuli and simulated loads. Besides actual sensor data, ADAS application needs supplementary vehicle data from other ECUs, which is usually transmitted via the CAN bus. This data includes details like gear rate, acceleration, engine speed, steering angle, or GPS data. ADAS requires such information to check the plausibility of the situation analysis. The ADAS makes safety-critical interventions only if all this information is consistent. One advantage of using physical sensors in HIL testing is that there’s no need to modify the unit under test (UUT) for testing purposes. Assuring the quality of injected signals is just one of many looming challenges.
QAC is preparing for the future of automated and connected vehicles through research and testing. Advanced systems like autonomous vehicles are quickly rewriting the rules for how test and measurement equipment vendors must design instrumentation. In the past, test software was merely a mechanism to communicate a gauged result or measure voltage levels. Now, test software is the technology that allows engineers to construct increasingly complex measurement systems capable of characterizing everything from the simplest components to comprehensive autonomous vehicle simulation.
How the HardWARE-In-the-Loop automotive System integration testing framework works
The QAaR team has developed new technologies for performing automotive SIT using HIL methods. A set of components, and their relationship in a vehicle representation (meta-model), has been developed; based on that model, test cases are generated and executed. A central controller manages and monitors each component of the test bench. Said controller executes each test scenario by comparing the initial state of all components with their final state after stimulations activator component stimulation. Activators are components that impact other connected applications when changing their state. For example, changing gears from Parking to Reverse. This action might affect several components such as the Back Camera, Back Sensor, or Multimedia Volume, etc. The team also developed a different approach for detecting the current state of each component. Listeners are methods able to, through analogue, digital and CAN bus messages, identify and interpret which state, without necessarily have access to the source-code of devices or drivers. This Blackbox-HIL-SIT approach has advantages, described below.
- Independent of infotainment operating System architecture and versions (independent of AGL, QNX or any other OS)
- Automotive HIL test framework focused on system integration testing across vehicle architecture pillars (infotainment, instrument cluster, heads-up display, telematics, and AUTOSAR)
- Verification of all devices and components, part of the automotive ecosystem and test scenario being validated, ensuring they work together properly
- Connectivity testing for head units, IoT components, and devices in a vehicle
- An automated process to prioritize automotive test cases according to ISO 26262 guidelines, based on ASIL levels, and focus on high-risk test execution scenarios
- Easy to edit and maintain test case adaptability while adding components and creating new listeners for specific products and vehicles
